Product description: High voltage line AC/DC 30/50/70/150/200KV2.5mm2 silicone high temperature resistant wire sheath is made of super soft and environmentally friendly silicone rubber, tightly wrapped, low eccentricity,
INQUIRY

High voltage line AC/DC 30/50/70/150/200KV2.5mm2 silicone high temperature resistant wire sheath is made of super soft and environmentally friendly silicone rubber, tightly wrapped, low eccentricity, effectively enhancing tensile strength and flexibility, wear resistance, acid and alkali resistance, oil resistance, aging resistance, long service life, tinned copper wire conductor, resistance Good oxidation.
High voltage AC/DC 30/50/70/150/200KV2.5mm2 silicone high temperature resistant wire Features:
1. Rated voltage: AC 10KV, 15KV, 20KV, 30KV, 50KV, 70kv, 150kv, 200kv
2. Working temperature: -60～+200℃
3. Conductor: stranded tinned oxygen-free copper wire
4. Insulation: high standard silicone rubber
5. Sheath: super soft and environmentally friendly silicone rubber

5. Color: red/black/white, etc.

Conductor			Insulation
Conductor			3KV		6KV		10KV		20KV		50KV
AWG	Conductor construction NO. *φ mm	Diameter mm	Insulation Thick mm	Overall Diameter mm	Insulation Thick mm	Overall Diameter mm	Insulation Thick mm	Overall Diameter mm	Insulation Thick mm	Overall Diameter mm	Insulation Thick mm	Overall Diameter mm
26	7*0.15	0.49	0.5	1.49	0.7	1.89	1	2.49	1.3	3.09	2.5	5.49
24	7*0.20	0.6	0.5	1.6	0.7	2	1	2.6	1.3	3.2	2.5	5.6
22	7*0.26	0.78	0.5	1.76	0.7	2.14	1	2.78	1.3	3.36	2.5	5.76
20	7*0.30	0.91	0.5	1.91	0.7	2.31	1	2.91	1.3	3.51	2.5	5.91
18	7*0.40	1.17	0.5	2.17	0.7	2.57	1	3.17	1.3	3.77	2.5	6.17
16	7*0.50	1.5	0.5	2.5	0.7	2.9	1	3.5	1.3	4.1	2.5	6.5
14	43*0.25	1.83	0.6	3.03	0.8	3.43	1.2	4.23	1.5	4.83	3	7.83
