Silicone rubber control cable

  • Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P
Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P

Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P

  • Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P
  • Product description: Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P make the temperature stable and protect it from mechanical collision. It is suitable for use in furnaces, motors, a
  • INQUIRY

Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P make the temperature stable and protect it from mechanical collision. It is suitable for use in furnaces, motors, aircraft structures, steel mills and hot rolling mills, as well as in areas where high temperature and extreme temperature differences occur. Suitable for AC 1KV and below with special requirements such as tension resistance, heat resistance, corrosion resistance and other mobile devices, trolleys, transmission machinery and power transmission lines for electrical appliances and control, lighting, communication lines. This product has been widely used in metallurgy, power, chemical industry, ships, ports and other industries.

Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P

silicone rubber multicore cable SiHF/GL-P

Heat-resistant halogen-free steel braiding silicone rubber multicore cable SiHF/GL-P Usage characteristics
1. The rated working voltage U0/U is 0.6/1KV.
2. The permissible high working temperature of cable conductor for a long time is 90°C and 180°C.
3. When the cable is short-circuited (no more than 5S for a long time), the working temperature is 250°C.
4. The bending radius of the silicone rubber cable is not less than 6 times of the actual outer diameter of the cable.
